400A High Current Carbon Brush Slip Ring with Electric Power for Marine
  • 400A High Current Carbon Brush Slip Ring with Electric Power for Marine
  • 400A High Current Carbon Brush Slip Ring with Electric Power for Marine
  • 400A High Current Carbon Brush Slip Ring with Electric Power for Marine
  • 400A High Current Carbon Brush Slip Ring with Electric Power for Marine
400A High Current Carbon Brush Slip Ring with Electric Power for Marine

400A High Current Carbon Brush Slip Ring with Electric Power for Marine

Place of Origin China
ชื่อแบรนด์ CENO
ได้รับการรับรอง CE,RoHS,UL,ISO9001
Model Number BHCN-C-04400-0560-42S
รายละเอียดสินค้า
Current & Circuits:
3 * 400A; 1 * PE; 3 * 60A; 2 * 60A; 6 * 16A; 36 * 10A
Rating voltage:
0~400 VAC/VDC; 220 VAC/24VDC
Dielectric strength:
≥1500VAC@50Hz; ≥1000VAC@50Hz
Isolation resistance:
≥500MΩ@500VDC; ≥300MΩ@500VDC
Contact resistance:
≤10mΩ(50rpm)
Working Temperature Storage Temperature:
-20°C~+60°C
Working humidity:
100%RH
IP protection grade:
IP54
Operating speed:
0~5 Rpm
Contact material:
Copper graphite; Precious Metal; Gold-plated
Housing material:
Customized
Encoder Model:
Customized
Maintenance:
On Schedule
Rotation method:
Brush stating, circuits rotating
Installation:
Rotor: Flange installation Staotr: Mounting holes
เงื่อนไขการชําระเงินและการจัดส่ง
Minimum Order Quantity
1pcs
ราคา
สามารถต่อรองได้
Packaging Details
Crate/As request
Delivery Time
2 weeks
Payment Terms
L/C, T/T,Paypal,Western Union
คําอธิบายสินค้า

 400A High Current Carbon Brush Slip Ring with Electric Power for Marine


BHCN-C-04400-0560-42S is CENO carbon brush slip ring with electric power named central collector and also called High current slip ring, large power slip ring, carbon brush slip ring, marine slip ring, can transmit high current 100A or higher, often apply to the marine machinery, engineering machine, Harbour machinery, such as marine crane, offshore platform crane, cable drum, Thruster or boat’s propeller and drilling plat form etc. For more information please contact us.




Features

  • Imported copper graphite, stable performance,less dust & long life
  • Excellent weather resistance, High electrical safety,Special design and easy maintenance


Applications

  • Marine crane
  • Offshore platform cran
  • Seaport machinery
  • Engineering machinery
  • Oil drilling platform


Optional

  • Circuit, Voltage, Current
  • Signals and data
  • Contact / Housing Materials
  • Protection grade
  • Working speed & temperature




Specification

BHCN-C-04400-0560-42S                         Specification
Working temperature-10°C~+45°C
Working humidity90 %RH
IP protection gradeIP54
Operating speed0~5rpm

Rating Voltage0 ~ 400 VAC/VDC
Current & Circuits3 * 400A; 1 * PE; 3 * 60A; 2 * 60A
Dielectric strength≥1500VAC@50Hz
Isolation resistance≥500MΩ@500VDC
Contact resistance wave≤ 10mΩ
Contact materialCopper carbon
Connect typeScrew connect terminal
MaintenanceOn schedule

Rating Voltage0 ~ 220 VAC/VDC
Current & Circuits6 * 16A; 36 * 10A
Dielectric strength≥1000VAC@50Hz
Isolation resistance≥300MΩ@500VDC
Connect materialPrecious metal
Connect typeConnect wire box
MaintenanceFree
Rotation methodCircuits rotating, brush stable
OtherHeater and temperature controller



Outline Drawing
400A High Current Carbon Brush Slip Ring with Electric Power for Marine 0






More information about ceno marine carbon brush slip rings


CENO Electronics has been designing and manufacturing slip rings for various industries for about 20 years. Our Carbon Brush Slip Ring is specially designed for marine and offshore applications, making sure your equipment runs smoothly and efficiently.
Our Carbon Brush Slip Ring has 7 circuits for 200A (400V), 1 circuit for PE, 6 circuits for 63A (400V), and 40 circuits for 5A signal. This product stands out with its large current capacity, which is perfect for marine and offshore applications. The high-quality materials used in construction ensure that our slip rings can withstand harsh and corrosive environments.
Our Carbon Brush Slip Rings also feature low electrical noise and minimal contact resistance, which can maintain the integrity of your signal transmission and power delivery. With CENO Electronics, you can trust that our slip rings are reliable and efficient, ensuring that your machinery operates safely and efficiently.
In conclusion, CENO Electronics has developed a Carbon Brush Slip Ring that is specifically designed to meet the needs of marine and offshore applications. With its large current capacity, low electrical noise, and high-quality construction materials, it is an excellent choice for any industrial application. Trust CENO Electronics for all your slip ring needs.





Application pictures

400A High Current Carbon Brush Slip Ring with Electric Power for Marine 1400A High Current Carbon Brush Slip Ring with Electric Power for Marine 2400A High Current Carbon Brush Slip Ring with Electric Power for Marine 3


Why with CENO

CENO is one technologically company in slip ring field who engages research and development,manufacturing and sales.We have advanced equipment and high precision test instruments to ensure products quality and reliable performance.Facility area covers 3000 square meters and located in Shenzhen China.





Certification

ISO9001,CE,RoHS,UL,Explosion-proof



CENO Advantage

Member in engineering team have more than 10 years experience in slip ring's field.Operators work on critical procedure are all qualified by internal training.



Service CENO provides

24 hours,7days consultant service.

Mass and customized production.

Solution offerring for 360° rotation system.





Welcome to consult us with your requests for any 360° rotation system.We will provide one stop service to you timely respond your inquiries.
